| Product Name: | LED Mining Headlamp | Light Source: | One Main Light Two Auxiliary Llights |
|---|---|---|---|
| Brightness: | 18000lux | Batrry Capacity: | 1000mAh |
| Main Light Current: | 600mA - 1000mA | Charging Ways: | Desktop Charger, USB Charger |
| Waterproof Grade: | IP68 | Usage: | Mining,oil,gas,other Speical Environment |
| Color: | Green+Black | Customzied Service: | Engraved LOGO, Customize Color Etc. |
1000mAh 18000LUX LED Miner Safety Lamp headlight Light miner's lamp Lamp with Charger
Features of GLS-6 Corded cap lamp:
High-Performance semi-corded cap lamp- GLS-6
➢IP68 water-proof
➢Rubber coating process
➢Impact-resistant
➢Anti-explosive
➢OLED screen with more information display
➢Panasonic high capacity battery
➢Strong engineer plastic
➢RGB rear warning light
New led cap lamp design, especially for industrial usage.
Applicate environment: underground coal/gold/metal mines, drilling well, tunnel cove lighting and other dust, humidity, rain, tremors, compressive environment, and under the environment of corrosive gaslighting.
Other types of RGB color special led cap lamp:
Special color for unique mining environment worksite, like RED, BLUE, GREEN single color for lighting.
2. Technical specifications of GLD-6 new wire headlamp:
| Model | GLS-6 |
| Light source | 1pcs main light 2pcs auxiliary lights |
| Battery Capacity | 6.8Ah |
| Rated Voltage | 3.7V |
| Main light current | 600mA(work) , 1100mA(strong) |
| Power of main light | 2.3W(work) , 3.7W(strong) |
| Illuminous | 481LUM |
| Brightness | 13000lux(work) ,18000lux(strong) |
| Life span of main light | 100000 Hours |
| Battery cycles | 1200 cycles |
| Working time | 16hrs(normal) , 8hrs(strong) |
| Weight | 480g including battery |
| Water-proof grade | IP68 |
3. Advantages of GLS-6 to compared with others:
1. OLED screen: display time, battery capacity, date or Customize LOGO, and company information.
Advantage: Safety lighting usage: you can charge your miner light when power nearly run out.
2. USB charger and magnetic connecting charging spot.
Advantage: Convenient. You can charge it on the car, computer, power bank.
3. All in one structure.
Advantage: perfect waterproof IP68.
4. 5V 2A charger.
Advantage: fast charging.
5. Light cap lamp weight and balance.
Advantage: Portable.
6. Superior brightness:
16000lux work lighting brightness and 25000lux super brightness is supplied up to your options.
7. SOS lighting mode.
Advantage: safe working in an emergency.
8. Auxiliary light:
Advantage: when lower power, you can use AL to get more working lighting time.
9. Detachable structure
Advantage: repair or replace inside parts is available, bring you 'use again'.
10. Special material
Advantage: flame retardant material with anti-explosive, flame-resistant, impact-resistant.
11. Adjustable stainless steel clip to change lighting angle.
12. Lighting levels: Work light - Strong light - auxiliary light - SOS.
13. Lithium Panasonic battery pack with battery mainboard
Advantage: electrical short circuit protection, over-charging, and over-discharging protection.
14. Push Switch
Easy and comfortable to turn off/on miner lights, time setting, more handy and convenient to push.
15. The front case with the highly permeable tempered lens, the lamp brightness also with a big increase.
16. Waterproof and dustproof IP68.
Full-sealing all in one structure.
17. Lightweight and high-intensity engineering plastic material.
Zhou Chuang Technology professionally manufactured safety lockout and tagout, led mining cap lamp, led strip light charging rack, and related accessories.For more products pls viewed www.zhouchuangsz.com
Troubles and troubleshooting of Underground Cap Lamps
| Description | Analysis | Troubleshooting |
| Light is not bright |
Switch contact is bad / Led source is broken |
Inspect the switch, measure the circuit, If the switch contact is good, then check the voltage of LED and the circuit or contact the manufacturer. |
| Not Light enough time | Undercharge |
First, check the contact points, and then charge according to the regulation. |
|
New lamp use without cycle charge before |
Precycling charge according to the regulations. | |
| The Lifespan of the battery is over | Replace the new lamp | |
| Illumination is not enough | Low battery voltage |
Measure the battery voltage, ensure charging time up to 7hours. |
| The glass is a serious pollution | Can wash the lens surface of the lamp by water. | |
|
The lamp can't charge or long charging time |
Charger (rack) a breakdown or battery damages, charge manager fault |
Check the charger's output voltage and current, if all normal, check the battery, measure its internal resistance and capacity. If not up to technical requirements, replace charger or contact the manufacturer. |
| Can't rotate on the fixed point | The screws of the clip are started | Fasten the screw appropriately |
